Monnayeur GRIDPR

NOTE

CODE

F

GB

D

Qté

1

MGR 001

Chassis nu

Frame

Halter

1

2

MGR 002

Couvercle butée ep. 2mm

Tokenthrough cover

Chips kappe

1

3

MGR 003

Bague D . 4 X 2 laiton

Ring

Ring

2

4

MGR 004

Ressort noyau 6 x 21

Axle spring

Achsefeder

1

5

MGR 005

Ressort volet 0.40 X 3

Shutter spring

Klappefeder

1

6

MGR 006

Ressort barette

Selector spring

Chipsfinger Feder

2

7

MGR 007

Noyau

Axle

Achse

1

8

MGR 008

Carte de commande

PCB

PCB

1

9

MGR 009

Micro rupteur G

Left microswitch

Mikroschalter Links

1

10

MGR 010

Micro rupteur D

Right microswitch

Mikroschalter Rechts

1

12

MGR 012

Ressort conique

Spring

Feder

1

21

MGR 021

Bille d. 7

Ball Diam 7

Rolle Diam 7

2

22

X 6021

Electro aimant 15 v

Coil 15 v

Spule 15 v

1

23

X 6022

Electro aimant 24 v

Coil 24 v

Spule 24 v

1

24

X 6023

Electro aimant 80 v

Coil 80 v

Spule 80 v

1

26

MGR 026

Triac

Triac

Triac

2

27

MGR 027

Diode

Diode

Diode

1

31

MGR 031

Petit chassis alu 1,2,3

Small alu frame

Kleinhalter

1

41

MGR 041

Grand chassis alu 4,5

Large alu frame

Grosshalter

1

51

MGR 051

Butée de jeton 1,3,4

Tokens stop

Chips

1

61

MGR 061

Doigt de retenue 1,2,3

Tokens finger

Chipsfinger

1

71

MGR 071

Volet 1,2,3

Shutter

Klapper

1

81

MGR 081

Barette jeton No.1

Token selector No. 1

Chipsfinger No. 1

1

82

MGR 082

Barette jeton No.2

Token selector No. 2

Chipsfinger No. 2

1

83

MGR 083

Barette jeton No. 3

Token selector No. 3

Chipsfinger No. 3

1

84

MGR 084

Barette jeton No. 4

Token selector No. 4

Chipsfinger No. 4

1

85

MGR 084

Barette jeton No. 5

Token selector No. 5

Chipsfinger No. 5

1

91

MGR 091

Pion D. 7

Ball centring part

Rollezentrierung

2

1000

MGR 1000

Plaque No. 1

Front plate No.1

Platte No. 1

1

2000

MGR 2000

Plaque No.2

Front plate No. 2

Platte No. 2

1

3000

MGR 3000

Plaque No. 3

Front plate No. 3

Platte No. 3

1

4000

MGR 4000

Plaque No. 4

Front plate No. 4

Platte No. 4

1

5000

MGR 5000

Plaque No. 5

Front plate No. 5

Platte No. 5

1
